Pneumatic Submersible Pump

Product Description | Product Application | Product Notes| Product DOSE
Suitable to empty ballast tanks,bilge wells,etc.in emergency cases often used for draining cargo and after the washing procedure.especially preferred where an electric spark may risk ignition or explosion .air pressure is 0.59MPa(6kgf/cm2)
Code:
RXSOL-21-2148-008
Other Equivalent Brand

Pneumatic Sump Pump

Short Description:
Suitable to empty ballast tanks bilge wells etc.in emergency cases often used for draining cargo.
Generic Name:
Pneumatic Sump Pump
Add to Compare
|
Compare Now
Video not available
Related Products:
Pneumatic Submersible Pump
Application:
  IMPA CODE CAPACITY  MAX. ALR CONSUMPTION WATER HOUSE SIZE [+] Read More...
Using Procedure:
Note:
Intended use: STROKE Pneumatic submersible pumps are intended or use de-watering,transfer of fluids such as clear and sea water. Marine emptying of ballast tanks,damming cargo holds and pumping and sea w [+] Read More...
Technical Specifications:

STORAGE:

When storing a sump pump for any length of time precautions should be taken to prevent corrosion and to maintain the pump in a serviceable condition.

  • Remove discharge and exhaust hose or pipe and run a pump out of water to blow out all moisture.

  • Remove the air line and pour a small amount of rust resistant oil in the live air inlet, re-connect hose and idle motor for a few minutes to carry oil to all internal parts.

  • Remove air hose and plug air inlet and air exhaust post with corks.

  • Wipe out the pump with rust resisting oil. Wrap pump in oiled paper and pack in covered box.

  • Store pump in dry place.

  •


Sr.no

Description

Causes

1

Pump stopped and will not start

Insufficient air pressure

Check air pressure is as recommended at the pump air inlet.

Air filtered blocked

Check if debris has clogged the inlet filter on the FRL unit/pump inlet air valve(some models have air filter on the air inlet valve) and ensure clear passage of air

Internal damage or excessive wear on components

Proceed to dismantle the pump, examine components for wear,replace any worn components, reassemble carefully as instructed in this manual and re-start the pump.

2

Pump runs slowly, poor delivery.

Insufficient or wrong lubricant in the air supply.

Ensure that the lubricant is as per the recommended chart, a thicker lubricant aften makes the air valve work sluggishly.


Internal damage or excessive wear on components

Proceed to dismantle the pump,examine components for wear, replace any worn components,ressemble carefully as instructed in this manual and re-start the pump.

3

Motor is jammed

Worn or damaged rotor blades

Dis-assemble governor housing (7)and motor housing (35) clean all parts in a light solvent.replace worn or damaged parts and reassemble.
