RO Antiscalant Aquatec 3000 is a powerful, broad spectrum, liquid antiscalant and dispersant that is compatible with organic coagulants. It is highly effective at low dose rates and in a wide range of feedwaters.
Code:
RXSOL-33-3343-250
Other Equivalent Brand
VITECH 3000
Short Description:
RO Antiscalant Aquatec 3000 is a Powerful, Broad spectrum, liquid antiscalant and dispersant that is compatible with organic coagulants. It is highly effective
RO Antiscalant Aquatec 3000 is a multicomponent antiscalant that prevents scale precipitation and disperses colloidal particles in cellulose acetate and polyamide membrane systems. It is compatible w [+] Read More...
Using Procedure:
INSTRUCTIONS FOR USE
Injecting
Best results are achieved when RO Antiscalant Aquatec 3000 is injected downstream of multimedia filters and upstream of cartridge filters.
Dosing
A typical RO Antis [+] Read More...
Note:
Future , Performence and Benefit ::
Powerful against these and other types of scale:
Calcium Carbonate
CaCO3
Barium Sulfate
[+] Read More...
Bentonite Supplier for Oil Field Industries. It is a drilling-grade Bentonite which is naturally occurring clay. It is a High Yield Natural Sodium montmorillonite. It meets API 13A Standards. Bentonit [+] Read More...
Code:
RXSOL-81-8101-050
Other Equivalent Brand
Bentonite API, Montmorrilonite
Short Description:
Maximum swelling property, while combine with water, Our fine quality of sodium bentonite having more water absorption capacity then ordinary one.
Generic Name:
Sodium Montomorillonite
Information:
Bentonite premium quality products exporter from India to Middle East - Dubai.
• It is Viscosifier and Filtration control agent for water based Mud Systems.
• It is used in drilling muds for controlling bore hole stability. It is utilized in drilling muds to extract drill cutti [+] Read More...
Using Procedure:
Bentonite can be Broadely classified in 2 grades :
Granular: Granular is the preferred option for filling trenches where the conductor is covered with Bentonite and then water poured over and mixed in t [+] Read More...
Note:
Advantage
• It helps improve hole cleaning capacities of drilling fluids.
• It is effective as a filtering agent.
• It promotes borehole stability.
• It can be added directly to fresh water or fresh water based drilling fluids.
Technical Specifications:
Difference Between Sodium Bentonite and Calcium Bentonite :
Bentonite is naturally occurring hydrated Alumina Silicate, there are two main varieties, calcium and sodium, where sodium Bentonite is the more commercially important. Calcium Bentonite deposits are much more common than sodium Bentonite deposits. However, calcium Bentonite can be changed to sodium Bentonite by the ion exchange process. The swelling type or sodium Bentonite, which has single water layer particles containing Na+ as the exchangeable ion. The other has double water layer particles with Ca++ as the exchangeable ion. It is called calcium Bentonite or non-swelling type.The clay-water characteristics are of primary importance. The chemical composition of the Bentonite is a consideration only because changes in physical properties accompany changes in chemical composition. Sodium Bentonite swells or expands to a greater degree than its calcium equivalent. Small percentage of cation exchange sites are occupied by another ion, such as calcium, a state is developed in the clay which promotes both optimum swelling and fastest hydration. Sodium Bentonite has higher swelling capacity, this property develops higher viscosity in suspensions, greater state of disaggregation, formation of smaller clay particles or greater colloidal properties.
Composition of Bentonite
Percentage value
Part Number
RXSOL-81-8101-050
SiO2
70,A2%
Ai2O3
15.9,A1.5%
Fe2O3
2.3,A0.1%
FeO
0.95,A0.1%
CaO
0.96, A0.1%
MgO
1.91, A0.1%
NaO
1.80, A0.1%
TiO2
0.04, A0.01%
K2O
0.78, A0.01%
Caustic Soda
0.55, A0.1%
Caustic Soda 0.55, A0.1%
TiO2 0.04, A0.01%
TiO2 0.04, A0.01%
TiO2 0.04, A0.01%
TiO2 0.04, A0.01%
TiO2 0.04, A0.01%
K2O 0.78, A0.01%
K2O 0.78, A0.01%
Remarks:
Physical State
:Free Flowing Powder
Viscometer Dial reading at 600 r/min
: Min 30
Yield Point/Plastic Viscosity Ratio
: Max 3
Residue of diameter greater than 75um
: Max mass friction 4,0%
Filtrate Volume
: Max 15.0 Cm3
Moisture
: 10% wt percent max
Various grade of Bentonite :::
Drilling Grade 1
API 13A Section – 9 Grade Bentonite Powder:
Physical Analysis:
PROPERTIES
PROTOCOL
UNIT
REQUIRED
RESULT
Viscometer Dial Reading at 600 rpm
API Spec. 13A:2004/ ISO 13500: 1998
r/min
30
36
Yield Point / Plastic Viscosity Ratio
API Spec. 13A:2004/ ISO 13500: 1998
_
3 Max
2.5
Filterate Volume
API Spec. 13A:2004/ ISO 13500: 1998
ML
15 Max
14.6
Moisture Content
API Spec. 13A:2004/ ISO 13500: 1998
% by weight
10.0 max.
10
Dry Screen Analysis(Residue Greater than 75 Microns)%
